Official Factory parts catalog for the Canon Pixma Pro 9500 printer.

Covers the following models:

0373B001AA PIXMA Pro9500/ 120V(US)
0373B002AA PIXMA Pro9500/ 120V(CA)
0373B008AA PIXMA Pro9500/ 220V-240V(ASA HVT)
0373B009AA PIXMA Pro9500/ 220V-240V(AU)
0373B012AA PIXUS Pro9500/ 100V(JP)
0373B015AA PIXMA Pro9500/ 220V-240V(CN)
0373B016AA PIXMA Pro9500/ 220V-240V(EU)

34 pages in pdf format showing exploded views and part numbers

FIGURE 1 PRINT HEAD & AC ADAPTER
FIGURE 2 OPERATION PANEL UNIT & MAIN CASE UNIT
FIGURE 3 FRONT DOOR/GEAR GUIDE UNIT
FIGURE 4 BOTTOM CASE UNIT & INK ABSORBER
FIGURE 5 LOGIC BOARD ASS'Y
FIGURE 6 SHEET FEED UNIT
FIGURE 7 CARRIAGE UNIT
FIGURE 8 PURGE UNIT
FIGURE 9 PLATEN UNIT
FIGURE 10 PAPER FEED PART

---

Keywords: parts;catalog;canon;pro 9500
File Size: 2410 KBytes
